Chipset: AMD B650• CPU: Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop ProcessorsSocket AM5 • Memory: 2x DDR5, Maximum Memory Capacity 128GB Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency:• 1DPC 1R Max speed up to 6800+ MHz• 1DPC 2R Max speed up to 6000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO • Onboard Graphics: 1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz (Available only on processors featuring integrated graphics) 1x VGA Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60HzGraphics specifications may vary depending on the CPU installed. • Slot: 1x PCI-E x16 slot:• Supports x16 (For Ryzen™ 9000/ 7000 Series processors)• Supports x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)• Supports x4 (For Ryzen™ 8500/ 8300 Series processors) 1x PCI-E x1 slot• PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)• PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) • Audio: Realtek® ALC897 Codec 7.1-Channel High Definition Audio • Storage: 1x M.2• M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices 4x SATA 6G • RAID: Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices • USB: 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) • LAN: Realtek® RTL8125BG 2.5G LAN • Internal IO: 1x Power Connector (ATX_PWR) 1x Power Connector (CPU_PWR) 1x CPU Fan 2x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector (JRGB) 1x TPM pin header (Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports • LED Feature: 4x EZ Debug LED • Back Panel Ports: HDMI™ VGA Keyboard/Mouse USB 3.2 Gen 1 5Gbps (Type-A) LAN port Audio connectors USB 2.0 • Operating System: Support for Windows® 11 64-bit, Windows® 10 64-bit

Read more less

Motherboard Specification: Processor Support: AMD Ryzen™ 8000/7000 Series Desktop Processors Chipset: AMD X670 Memory Support: 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz Graphics Ports: 1x HDMI™ (HDMI™ 2.1) 1x DisplayPort (DP 1.4) Expansion Slots: 3x PCI-E x16 slot 1x PCI-E x1 slot Storage: 4x M.2 4x SATA 6G Ethernet: Realtek® RTL8125BG 2.5Gbps LAN Wireless & Bluetooth: AMD Wi-Fi 6E, Bluetooth® 5.3 USB: 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 4x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) Audio: Realtek® ALC897 Codec, 7.1-Channel High Definition Audio Internal I/O Connectors: Various power connectors, fan connectors, front panel connectors, USB headers, RGB LED connectors, TPM pin header, and USB4 card connector. Back Panel I/O Ports: HDMI™, DisplayPort, USB ports (2.0, 3.2 Gen1, 3.2 Gen2 Type A, 3.2 Gen2 Type C), USB4 card connector, LAN port, and audio ports. Form Factor: ATX

Read more less

Comprehensive cooling: VRM heatsink, PCH heatsink, and Fan Xpert 2+ Ultrafast connectivity: M.2 support, 1 Gb Ethernet, and USB 3.2 Gen 2 Type-A 5X Protection III: Multiple hardware safeguards for all-around system protection Aura Sync RGB Lighting: Onboard connector for RGB LED strips, easily synced with an ever-growing portfolio of Aura Sync-capable hardware

Read more less

TUF GAMING Z790-BTF WIFI Motherboard Specifications Processor Support:Intel® Core™ 14th, 13th, 12th Gen, Pentium® Gold, Celeron® (LGA1700)Chipset:Intel® Z790Memory Support:4 x DDR5 slots, up to 192GB, 7200(OC) MHzGraphics Ports:1 x DisplayPort 1.4 (4K@60Hz), 1 x HDMI™ 2.1 (4K@60Hz)Expansion Slots:1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16 (x4 mode), 1 x PCIe 4.0 x4Storage:4 x M.2 slots, 4 x SATA 6Gb/s portsEthernet:Intel® 2.5GbWireless & Bluetooth:Wi-Fi 7 (802.11be), Bluetooth® v5.4USB:Rear: 1 x USB 20Gbps (Type-C®), 3 x USB 10Gbps, 4 x USB 5GbpsFront: 1 x USB 10Gbps (Type-C®), 1 x USB 5Gbps header, 2 x USB 2.0 headersAudio:Realtek ALC1220P 7.1 Surround, S/PDIF outInternal I/O Connectors:Fan headers, Power connectors, M.2, SATA, USB headers, RGB headersBack Panel I/O Ports:USB, DisplayPort, HDMI™, Ethernet, Audio jacksForm Factor:ATX (30.5 cm x 24.4 cm)

Read more less

Motherboard Specification: Processor Support: Supports 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: Intel® Z790 Express Chipset Memory Support: DDR5 memory up to 7600MHz (OC), with support for up to 192GB Graphics Ports: HDMI and USB Type-C® ports supporting high resolutions Expansion Slots: PCIe 5.0 and PCIe 4.0 slots for GPU and other cards Storage: M.2 and SATA connectors for high-speed SSDs and HDDs Ethernet: Intel® 2.5GbE LAN chip Wireless & Bluetooth: Intel® Wi-Fi 6E AX211, Bluetooth 5.3 USB: Various USB ports including USB Type-C® with Gen 2x2 support Audio: Realtek® ALC1220-VB CODEC, High Definition Audio with S/PDIF Out support Form Factor: ATX Form Factor; 30.5cm x 24.4cm

Read more less

CPU Support: Intel® Core™ Ultra Processors (LGA 1851), supports Intel® Turbo Boost 2.0/3.0. Chipset: Intel® Z890. Memory: 4 x DIMM slots, up to 256GB DDR5, supports up to 8666+ MT/s (OC). Graphics: 1 x DisplayPort, 1 x HDMI 2.1 (4K@60Hz), 1 x Thunderbolt™ 4 USB Type-C® (8K@60Hz). Expansion: 1 x PCIe 5.0 x16, 3 x PCIe 4.0 x16 slots. Storage: 4 x M.2 slots, 4 x SATA 6Gb/s ports, supports RAID. Ethernet: Realtek 2.5Gb Ethernet. Wireless: Wi-Fi 7 (2x2) up to 2.9Gbps, Bluetooth 5.4. USB Ports: 1 x Thunderbolt™ 4 USB Type-C®, 1 x USB 10Gbps, 6 x USB 5Gbps, 4 x USB 2.0. Audio: Realtek 7.1 Surround Sound, HD Audio CODEC. Form Factor: ATX (12" x 9.6").

Read more less

Motherboard Specification: Processor Support: Intel® Socket LGA1700 for 13th & 14th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: Intel® B760 Chipset Memory Support: 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory Graphics Ports: 1 x DisplayPort, 1 x HDMITM port Expansion Slots: Intel® 13th & 12th Gen Processors: 1 x PCIe 5.0 x16 slot Intel® B760 Chipset: 1 x PCIe 3.0 x16 slot, 2 x PCIe 3.0 x1 slots Storage: Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports Intel® 13th & 12th Gen Processors: M.2_1 slot (Key M) supports PCIe 4.0 x4 mode Intel® B760 Chipset: M.2_2 slot (Key M) supports PCIe 4.0 x4 mode, M.2_3 slot (Key M) supports PCIe 4.0 x4 mode, 4 x SATA 6Gb/s ports Ethernet: 1 x Realtek 2.5Gb Ethernet Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2 USB: Rear: 1 x USB 3.2 Gen 2x2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 1 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC Internal I/O Connectors: Includes fan, power, storage, USB, and other headers Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Wi-Fi Module, Ethernet, audio, and S/PDIF out ports Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm) Motherboard Specification: Processor Support: Intel® Socket LGA1700 for 13th & 14th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: Intel® B760 Chipset Memory Support: 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory Graphics Ports: 1 x DisplayPort, 1 x HDMITM port Expansion Slots: Intel® 13th & 12th Gen Processors: 1 x PCIe 5.0 x16 slot Intel® B760 Chipset: 1 x PCIe 3.0 x16 slot, 2 x PCIe 3.0 x1 slots Storage: Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports Intel® 13th & 12th Gen Processors: M.2_1 slot (Key M) supports PCIe 4.0 x4 mode Intel® B760 Chipset: M.2_2 slot (Key M) supports PCIe 4.0 x4 mode, M.2_3 slot (Key M) supports PCIe 4.0 x4 mode, 4 x SATA 6Gb/s ports Ethernet: 1 x Realtek 2.5Gb Ethernet Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2 USB: Rear: 1 x USB 3.2 Gen 2x2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 1 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC Internal I/O Connectors: Includes fan, power, storage, USB, and other headers Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Wi-Fi Module, Ethernet, audio, and S/PDIF out ports Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm) Related items

Read more less

Ultrafast Connectivity: PCIe 5.0, three PCIe 4.0 M.2, Realtek 2.5Gb Ethernet, USB 3.2 Gen 2x2 Type-C®, front USB 3.2 Gen 1 Type-C® and Thunderbolt™ (USB4®) header support Comprehensive Cooling: VRM heatsinks, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+ Exclusive Memory Technology: ASUS Enhanced Memory Profile II and ASUS OptiMem II Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware

Read more less

Motherboard Specifications Chipset: Intel B760 CPU Support: Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold, and Celeron® Processors Socket LGA 1700 Memory: 4 x DDR5 slots, up to 256GB Supported Frequencies: DDR5 6800+(OC), 6600(OC), 6400(OC), 6200(OC), 6000(OC), 5800(OC), 5600(JEDEC), 5400(JEDEC), 5200(JEDEC), 5000(JEDEC), 4800(JEDEC) Max. Overclocking Frequencies: 1DPC 1R: Up to 6800+ MHz 1DPC 2R: Up to 6400+ MHz 2DPC 1R: Up to 6000+ MHz 2DPC 2R: Up to 5600+ MHz Supports Intel® XMP 3.0 OC Dual-Controller Dual-Channel mode Non-ECC, un-buffered memory Audio: Realtek® ALC897 Codec 7.1-Channel High Definition Audio Storage: 2 x M.2 Slots: M.2_1 (CPU): PCIe 4.0 x4, 2280/2260/2242 devices M.2_2 (Chipset): PCIe 4.0 x4 / SATA mode, 2280/2260/2242 devices 4 x SATA 6G ports Note: SATA5 is unavailable if an M.2 SATA SSD is installed in the M2_2 slot. LAN: Realtek® RTL8111H Gigabit LAN Onboard Graphics: 1 x HDMI™ 1.4: Up to 4K 30Hz 1 x DisplayPort 1.4: Up to 4K 60Hz 1 x VGA: Resolutions up to 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz Note: Graphics specifications depend on the CPU. Expansion Slots: 1 x PCI-E x16 slot (PCI_E1 Gen PCIe 4.0, from CPU) 2 x PCI-E x1 slots (PCI_E2, PCI_E3 Gen PCIe 4.0, from Chipset) RAID Support: RAID 0, RAID 1, RAID 5, RAID 10 for SATA storage devices USB Ports: Rear: 4 x USB 2.0 1 x USB 5Gbps Type-A 1 x USB 10Gbps Type-C Front: 4 x USB 2.0 2 x USB 5Gbps Type-A Internal I/O Connectors: 1 x ATX Power Connector 1 x CPU Power Connector 1 x CPU Fan 2 x System Fan 2 x Front Panel (JFP) 1 x Chassis Intrusion (JCI) 1 x Front Audio (JAUD) 1 x Printer Port (JLPT) 1 x Com Port (JCOM) 1 x RGB LED Connector (JRGB) 1 x TPM Pin Header (Support TPM 2.0) 4 x USB 2.0 Ports 2 x USB 5Gbps Type-A Ports LED Feature: 4 x EZ Debug LED Back Panel Ports: VGA DisplayPort HDMI™ Keyboard / Mouse USB 2.0 LAN port Audio Connectors USB 3.2 Gen 1 5Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) Operating System: Supports Windows® 11 64-bit, Windows® 10 64-bit Form Factor: mATX (243.84mm x 243.84mm)

Read more less

Motherboard Specification Processor Support: Intel® Core™ 14th/13th/12th Gen, Intel® Pentium® Gold, and Celeron® Processors Chipset: Intel® B760 Chipset Memory Support: 2 DIMMs, Dual Channel DDR4-4800+MHz (OC) Graphics Ports: HDMI™ 1.4 (4K@30Hz), VGA (Requires Processor Graphics) Expansion Slots: 1 × PCIe 4.0 x16, 1 × PCIe 3.0 x1 Storage: 1 × M.2 Gen4 x4 64Gbps, 4 × SATA 6Gbps Ethernet: Realtek® RTL8111H Gigabit LAN USB: 4 × USB 3.2 Gen 1 (Type-A), 8 × USB 2.0 Audio: 8-Channel (7.1) HD Audio with Audio Boost

Read more less

Motherboard Specification Processor Support: Intel® LGA1700 (Core™ 14th, 13th, 12th Gen, Pentium® Gold, Celeron®) Chipset: Intel® H610 Memory Support: 2 x DIMM slots, max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Graphics Ports: 1 x HDMI™ port (4K@60Hz) Expansion Slots: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1 Storage: 1 x M.2 slot (PCIe 3.0 x4), 4 x SATA 6Gb/s Ethernet: 1 x Realtek 1Gb Ethernet Wireless & Bluetooth: Not included USB: 2 x USB 5Gbps, 4 x USB 2.0 rear; 1 x USB 5Gbps, 1 x USB 2.0 front Audio: Realtek 7.1 Surround Sound Audio CODEC Internal I/O Connectors: 1 x 4-pin CPU Fan header, 1 x 4-pin Chassis Fan header, 1 x M.2 slot Back Panel I/O Ports: 2 x USB 5Gbps, 4 x USB 2.0, 1 x HDMI™, 1 x Ethernet, 3 x Audio jacks, 1 x PS/2 port Form Factor: micro-ATX (9.2 inch x 8.0 inch)

Read more less

Motherboard Specification: Processor Support: Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: H510 Memory Support: DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Graphics Ports: 1 x HDMI 2.0, 1 x DisplayPort, 1 x D-Sub port Expansion Slots: Intel® 11th & 10th Gen Processors: 1 x PCIe 4.0/3.0 x16 slot Intel® H510 Chipset: 2 x PCIe 3.0 x1 slots Storage: 1 x M.2 slot (Key M) supports PCIe 3.0 x4 & SATA modes 4 x SATA 6Gb/s ports Ethernet: 1 x Intel® 1Gb Ethernet USB: Rear: 2 x USB 3.2 Gen 1 ports, 4 x USB 2.0 ports; Front: 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers Audio: Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC Internal I/O Connectors: Includes fan, power, storage, USB, and other headers Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Ethernet, audio, PS/2 Keyboard, PS/2 Mouse ports Form Factor: microATX (22.6cm x 21.1cm)
