Technical Spec
Product Dimensions
125×92×150 mm(L×W×H)
Heatsink Dimensions
120×92×150 mm(L×W×H)
Net Weight
614 g
Heatpipe
Ø6 mm×4 pcs
Fan Dimensions
120×120×25 mm(L×W×H)
Fan Speed
500~2000 RPM±10%
Fan Airflow
75.89 CFM
Fan Air Pressure
2.53 mmAq
Fan Noise
≤31.6 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Hydro Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.28 A
Fan Power Consumption
3.36 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G)
LED Rated Voltage
5 VDC
LED Power Consumption
1.05 W
EAN
6933412727781
P/N
R-AG400-WHANMC-G-2
The included mounting brackets support both Intel and AMD platforms with an easy five-step installation process that maintains great contact pressure. The offset design of the heat pipes ensures that the cooler can be installed with the fan already attached
Fan Dimensions : 120×120×25 mm ; Fan Speed : 500~2000 RPM±10%
Support Intel - LGA1700/1200/1151/1150/1155 & AMD - AM5/AM4
Fan Airflow : 75.89 CFM ; Fan Air Pressure : 2.53 mmAq
Fan Noise : ≤31.6 dB(A) ; Fan Connector : 4-pin PWM
Fan Rated Current : 0.28 A ; Fan Power Consumption : 3.36 W
Compatibility: Intel LGA2066/2011-v3/2011/1700/1200/1151/1150/1155, AMD AM5/AM4
Product Dimensions: 129×136×157 mm (L×W×H)
Heatsink Dimensions: 127×110×157 mm (L×W×H)
Net Weight: 1300 g
Heatpipe: Ø6 mm×6 pcs
Fan Dimensions: 120×120×25 mm (L×W×H)
Fan Speed: 300~1850 RPM ±10%
Fan Airflow: 67.88 CFM
Fan Air Pressure: 2.04 mmAq
Fan Noise: ≤29.4 dB(A)
Fan Connector: 4-pin PWM
Bearing Type: Hydro Bearing
Fan Rated Voltage: 12 VDC
Fan Rated Current: 0.14 A
Fan Power Consumption: 1.68 W
LED Type: Addressable RGB LED
LED Connector: 3-pin (+5V-D-G)
LED Rated Voltage: 5 VDC
LED Power Consumption: 1.05 W
Excellent CPU cooling fan
Work, play and relax without worrying about your CPU's temperature with the Deepcool Alta 9 managing the processor's thermal condition. The fan can attain a top speed of 2200 and generates a maximum airflow of 42.35CFM on a hydro bearing that keeps operating noise at a low 26.3dBA.
The Deepcool Alta 9 CPU air cooler is specially-engineered to provide the most effective heat dissipation for processors that allow mounting via particular Intel CPU sockets. Its durable construction and entry-level price point, along with its efficient cooling performance, make it an excellent replacement to stock CPU air coolers.
The Deepcool Alta 9 Intel Socket CPU COOLER (DP-ICAP-AT9) is a high-quality therma
Radiator Dimensions (WxDxH): 282 x 120 x 27 mm
Radiator Material: Aluminum
Number of Fans: 2
Fan Dimensions (WxDxH): 120 x 120 x 25 mm
Fan Speed: 500~2250 RPM ±10%
Fan Air Flow: 85.85 CFM
Fan Noise Level: ≤32.9 dB(A)
Fan Bearing: Hydro Bearing
Fan Life Expectancy: Not provided
Fan Power Consumption: 3.0 W
PWM Mode: Yes
Fan Lighting: Addressable RGB LED
Pump Speed: 2400 RPM ±10%
Intel Socket Support: LGA1700/1200/1151/1150/1155
AMD Socket Support: AM5/AM4
Radiator Dimensions (WxDxH): 282×120×27 mm (L×W×H)
Radiator Material: Aluminum
Number of Fans: 2
Fan Dimensions (WxDxH): 120×120×25 mm (L×W×H)
Fan Speed: 500~2250 RPM ±10%
Fan Air Flow: 85.85 CFM
Fan Noise Level: ≤32.9 dB(A)
Fan Bearing: Hydro Bearing
Fan Power Consumption: 3.0 W
PWM Mode: Supported (4-pin PWM)
Fan Lighting: Addressable RGB LED
Pump Speed: 2400 RPM ±10%
Intel Socket Support: LGA1700/1200/1151/1150/1155
AMD Socket Support: AM5/AM4
Application For
Intel : LGA1700/1200/1151/1150/1155
AMD : AM5/AM4
Technical Specs
Net Weight : 1659 g
Radiator Dimensions : 402×120×27 mm(L×W×H)
Radiator Material : Aluminum
Tube length : 410 mm(L×W×H)
Pump Dimensions : 85×73×55 mm(L×W×H)
Pump Speed : 3100 RPM±10%
Pump Noise : 19 dB(A)
Pump Connector : 3-pin
Pump Rated Voltage : 12 VDC
Pump Rated Current : 0.38 A
Pump Power Consumption : 4.56 W
Fan Dimensions : 120×120×25 mm(L×W×H)
Fan Speed : 500~2250 RPM±10%
Fan Airflow : 85.85 CFM
Fan Air Pressure : 3.27 mmAq
Fan Noise : ≤32.9 dB(A)
Fan Speed (with LSP) : 500~1600 RPM±10%
Fan Airflow (with LSP) : 60.85 CFM
Fan Air Pressure (with LSP) : 1.65 mmAq
Fan Noise (with LSP) : ≤28.2 dB(A)
Fan Connector : 4-pin PWM
Bearing Type : Hydro Bearing
Fan Rated Voltage : 12 VDC
Fan Rated Current : 0.25 A
Fan Power Consumption : 3.0 W
LED Type : Addressable RGB LED
LED Connector : 3-pin(+5V-D-G)
LED Rated Voltage : 5 VDC
LED Power Consumption : 2.7 W （PUMP）/ 3.15 W（FAN×3）
EAN : 6.93341E+12
P/N : R-LS720-BKAMMM-G-1
