| CPU Support |
AMD AM5 socket – Ryzen™ 7000 / 8000 / 9000 Series |
| Chipset |
AMD B650 |
| Memory Support |
2 x DDR5 DIMM slots (up to 128 GB)
Supports DDR5-6400(OC) down to 4400 MT/s
Dual-channel architecture
Supports AMD EXPO™ and Intel XMP |
| Graphics Support |
Integrated graphics support via:
- 1 x HDMI 2.1 (4096x2160@60Hz)
- 1 x DisplayPort 1.4 (3840x2160@144Hz)
- 1 x D-Sub (1920x1200@60Hz)
Supports up to 3 displays simultaneously
|
| Audio |
Realtek® High Definition Audio
Supports 2/4/5.1/7.1-channel |
| LAN |
Realtek® 1GbE LAN |
| Expansion Slots |
- 1 x PCIe 4.0 x16 (for GPU / NVMe – from CPU)
- 1 x PCIe 3.0 x1 (from chipset) |
| Storage Options |
- 1 x M.2 PCIe 4.0 x4/x2 (CPU)
- 4 x SATA 6Gb/s
- RAID 0/1/10 for both NVMe & SATA |
| USB Ports |
Rear:
- 2 x USB 3.2 Gen 1
- 4 x USB 2.0
- 1 x USB 2.0
Internal:
- 2 x USB 3.2 Gen 1 (via header)
- 4 x USB 2.0 (via headers) |
| Back I/O Ports |
- 4 x USB 2.0
- 2 x USB 3.2 Gen 1
- HDMI, DisplayPort, D-Sub
- PS/2 keyboard/mouse
- RJ-45 LAN
- 3 x Audio jacks
- Q-Flash Plus button |
| Internal I/O |
- 1 x 24-pin ATX + 1 x 8-pin CPU power
- 1 x M.2 Socket
- 4 x SATA
- Fan headers, RGB headers, TPM, USB headers, Clear CMOS jumper |
| BIOS |
256 Mbit AMI UEFI BIOS
Q-Flash & Q-Flash Plus support |
| Software |
GIGABYTE Control Center (GCC), Norton® Security OEM |
| OS Support |
Windows 11 / 10 64-bit |
| Form Factor |
Micro-ATX (23.0cm x 22.5cm) |
