Description
Gigabyte B760M DS3H DDR5 GEN5 – LGA1700 Micro-ATX Motherboard for Intel 14th, 13th, and 12th Gen CPUs
Power up your next PC build with the Gigabyte B760M DS3H GEN5, a high-performance Intel B760 chipset motherboard designed to support the latest Intel® 14th, 13th, and 12th Generation Core™ processors. With support for DDR5 up to 7600MT/s, PCIe 5.0 for GPUs, and dual M.2 PCIe 4.0 SSDs, this Micro-ATX board delivers the speed and reliability modern gamers and creators demand.
Key Specifications:
| Feature |
Details |
| CPU Socket |
LGA 1700 |
| Chipset |
Intel® B760 Express |
| CPU Support |
14th / 13th / 12th Gen Intel® Core™, Pentium® Gold, and Celeron® |
| Memory Support |
4 x DDR5 DIMMs, up to 256GB
Up to 7600MT/s (OC) |
| PCIe Slots |
1 x PCIe 5.0 x16 (GPU)
2 x PCIe 3.0 x1 |
| Storage |
2 x M.2 PCIe 4.0 x4/x2 (2280)
4 x SATA 6Gb/s |
| Graphics Outputs |
HDMI 2.1, D-Sub, 2 x DisplayPort (up to 4 monitors) |
| Networking |
Realtek® 2.5GbE LAN |
| Audio |
Realtek® 7.1-Channel HD Audio with S/PDIF Out |
| USB Ports |
Rear: USB-C 3.2 Gen 2, 3 x USB 3.2 Gen 1, 2 x USB 2.0
Internal: USB 3.2 Gen 1 header, 6 x USB 2.0 |
| RGB Support |
2 x ARGB Gen2 headers
1 x RGB LED header |
| Cooling |
1 x CPU fan header, 3 x system fan headers |
| Form Factor |
Micro ATX (24.4 x 24.4 cm) |
| OS Support |
Windows 11 / 10 (64-bit) |
Special Features:
-
PCIe Gen 5 x16 slot for ultra-fast GPU performance
-
Supports quad display output for multitasking setups
-
ARGB Gen2 lighting control and RGB strip headers
-
Q-Flash Plus: Update BIOS without CPU or RAM
-
Smart Backup and GIGABYTE Control Center (GCC)
-
SATA RAID 0/1/5/10 support for added storage reliability
-
Heavy-duty power phase design for enhanced stability
Available now at Alfarah Store – your trusted destination for high-performance Intel motherboards in Iraq.
