Motherboard Specification: Processor Support: AMD Ryzen™ 8000/7000 Series Desktop Processors Chipset: AMD X670 Memory Support: 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200(OC)/5000(OC)/4800(JEDEC) MHz Graphics Ports: 1x HDMI™ (HDMI™ 2.1) 1x DisplayPort (DP 1.4) Expansion Slots: 3x PCI-E x16 slot 1x PCI-E x1 slot Storage: 4x M.2 4x SATA 6G Ethernet: Realtek® RTL8125BG 2.5Gbps LAN Wireless & Bluetooth: AMD Wi-Fi 6E, Bluetooth® 5.3 USB: 4x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 4x USB 3.2 Gen1 Type A (Front) 3x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) Audio: Realtek® ALC897 Codec, 7.1-Channel High Definition Audio Internal I/O Connectors: Various power connectors, fan connectors, front panel connectors, USB headers, RGB LED connectors, TPM pin header, and USB4 card connector. Back Panel I/O Ports: HDMI™, DisplayPort, USB ports (2.0, 3.2 Gen1, 3.2 Gen2 Type A, 3.2 Gen2 Type C), USB4 card connector, LAN port, and audio ports. Form Factor: ATX

Read more less

Comprehensive cooling: VRM heatsink, PCH heatsink, and Fan Xpert 2+ Ultrafast connectivity: M.2 support, 1 Gb Ethernet, and USB 3.2 Gen 2 Type-A 5X Protection III: Multiple hardware safeguards for all-around system protection Aura Sync RGB Lighting: Onboard connector for RGB LED strips, easily synced with an ever-growing portfolio of Aura Sync-capable hardware

Read more less

TUF GAMING Z790-BTF WIFI Motherboard Specifications Processor Support:Intel® Core™ 14th, 13th, 12th Gen, Pentium® Gold, Celeron® (LGA1700)Chipset:Intel® Z790Memory Support:4 x DDR5 slots, up to 192GB, 7200(OC) MHzGraphics Ports:1 x DisplayPort 1.4 (4K@60Hz), 1 x HDMI™ 2.1 (4K@60Hz)Expansion Slots:1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16 (x4 mode), 1 x PCIe 4.0 x4Storage:4 x M.2 slots, 4 x SATA 6Gb/s portsEthernet:Intel® 2.5GbWireless & Bluetooth:Wi-Fi 7 (802.11be), Bluetooth® v5.4USB:Rear: 1 x USB 20Gbps (Type-C®), 3 x USB 10Gbps, 4 x USB 5GbpsFront: 1 x USB 10Gbps (Type-C®), 1 x USB 5Gbps header, 2 x USB 2.0 headersAudio:Realtek ALC1220P 7.1 Surround, S/PDIF outInternal I/O Connectors:Fan headers, Power connectors, M.2, SATA, USB headers, RGB headersBack Panel I/O Ports:USB, DisplayPort, HDMI™, Ethernet, Audio jacksForm Factor:ATX (30.5 cm x 24.4 cm)

Read more less

Motherboard Specification: Processor Support: Supports 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: Intel® Z790 Express Chipset Memory Support: DDR5 memory up to 7600MHz (OC), with support for up to 192GB Graphics Ports: HDMI and USB Type-C® ports supporting high resolutions Expansion Slots: PCIe 5.0 and PCIe 4.0 slots for GPU and other cards Storage: M.2 and SATA connectors for high-speed SSDs and HDDs Ethernet: Intel® 2.5GbE LAN chip Wireless & Bluetooth: Intel® Wi-Fi 6E AX211, Bluetooth 5.3 USB: Various USB ports including USB Type-C® with Gen 2x2 support Audio: Realtek® ALC1220-VB CODEC, High Definition Audio with S/PDIF Out support Form Factor: ATX Form Factor; 30.5cm x 24.4cm

Read more less

CPU Support: Intel® Core™ Ultra Processors (LGA 1851), supports Intel® Turbo Boost 2.0/3.0. Chipset: Intel® Z890. Memory: 4 x DIMM slots, up to 256GB DDR5, supports up to 8666+ MT/s (OC). Graphics: 1 x DisplayPort, 1 x HDMI 2.1 (4K@60Hz), 1 x Thunderbolt™ 4 USB Type-C® (8K@60Hz). Expansion: 1 x PCIe 5.0 x16, 3 x PCIe 4.0 x16 slots. Storage: 4 x M.2 slots, 4 x SATA 6Gb/s ports, supports RAID. Ethernet: Realtek 2.5Gb Ethernet. Wireless: Wi-Fi 7 (2x2) up to 2.9Gbps, Bluetooth 5.4. USB Ports: 1 x Thunderbolt™ 4 USB Type-C®, 1 x USB 10Gbps, 6 x USB 5Gbps, 4 x USB 2.0. Audio: Realtek 7.1 Surround Sound, HD Audio CODEC. Form Factor: ATX (12" x 9.6").

Read more less

Motherboard Specification: Processor Support: Intel® Socket LGA1700 for 13th & 14th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: Intel® B760 Chipset Memory Support: 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory Graphics Ports: 1 x DisplayPort, 1 x HDMITM port Expansion Slots: Intel® 13th & 12th Gen Processors: 1 x PCIe 5.0 x16 slot Intel® B760 Chipset: 1 x PCIe 3.0 x16 slot, 2 x PCIe 3.0 x1 slots Storage: Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports Intel® 13th & 12th Gen Processors: M.2_1 slot (Key M) supports PCIe 4.0 x4 mode Intel® B760 Chipset: M.2_2 slot (Key M) supports PCIe 4.0 x4 mode, M.2_3 slot (Key M) supports PCIe 4.0 x4 mode, 4 x SATA 6Gb/s ports Ethernet: 1 x Realtek 2.5Gb Ethernet Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2 USB: Rear: 1 x USB 3.2 Gen 2x2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 1 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC Internal I/O Connectors: Includes fan, power, storage, USB, and other headers Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Wi-Fi Module, Ethernet, audio, and S/PDIF out ports Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm) Motherboard Specification: Processor Support: Intel® Socket LGA1700 for 13th & 14th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: Intel® B760 Chipset Memory Support: 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory Graphics Ports: 1 x DisplayPort, 1 x HDMITM port Expansion Slots: Intel® 13th & 12th Gen Processors: 1 x PCIe 5.0 x16 slot Intel® B760 Chipset: 1 x PCIe 3.0 x16 slot, 2 x PCIe 3.0 x1 slots Storage: Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports Intel® 13th & 12th Gen Processors: M.2_1 slot (Key M) supports PCIe 4.0 x4 mode Intel® B760 Chipset: M.2_2 slot (Key M) supports PCIe 4.0 x4 mode, M.2_3 slot (Key M) supports PCIe 4.0 x4 mode, 4 x SATA 6Gb/s ports Ethernet: 1 x Realtek 2.5Gb Ethernet Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2 USB: Rear: 1 x USB 3.2 Gen 2x2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 1 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC Internal I/O Connectors: Includes fan, power, storage, USB, and other headers Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Wi-Fi Module, Ethernet, audio, and S/PDIF out ports Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm) Related items

Read more less

Ultrafast Connectivity: PCIe 5.0, three PCIe 4.0 M.2, Realtek 2.5Gb Ethernet, USB 3.2 Gen 2x2 Type-C®, front USB 3.2 Gen 1 Type-C® and Thunderbolt™ (USB4®) header support Comprehensive Cooling: VRM heatsinks, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+ Exclusive Memory Technology: ASUS Enhanced Memory Profile II and ASUS OptiMem II Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware

Read more less

Motherboard Specifications Chipset: Intel B760 CPU Support: Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold, and Celeron® Processors Socket LGA 1700 Memory: 4 x DDR5 slots, up to 256GB Supported Frequencies: DDR5 6800+(OC), 6600(OC), 6400(OC), 6200(OC), 6000(OC), 5800(OC), 5600(JEDEC), 5400(JEDEC), 5200(JEDEC), 5000(JEDEC), 4800(JEDEC) Max. Overclocking Frequencies: 1DPC 1R: Up to 6800+ MHz 1DPC 2R: Up to 6400+ MHz 2DPC 1R: Up to 6000+ MHz 2DPC 2R: Up to 5600+ MHz Supports Intel® XMP 3.0 OC Dual-Controller Dual-Channel mode Non-ECC, un-buffered memory Audio: Realtek® ALC897 Codec 7.1-Channel High Definition Audio Storage: 2 x M.2 Slots: M.2_1 (CPU): PCIe 4.0 x4, 2280/2260/2242 devices M.2_2 (Chipset): PCIe 4.0 x4 / SATA mode, 2280/2260/2242 devices 4 x SATA 6G ports Note: SATA5 is unavailable if an M.2 SATA SSD is installed in the M2_2 slot. LAN: Realtek® RTL8111H Gigabit LAN Onboard Graphics: 1 x HDMI™ 1.4: Up to 4K 30Hz 1 x DisplayPort 1.4: Up to 4K 60Hz 1 x VGA: Resolutions up to 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz Note: Graphics specifications depend on the CPU. Expansion Slots: 1 x PCI-E x16 slot (PCI_E1 Gen PCIe 4.0, from CPU) 2 x PCI-E x1 slots (PCI_E2, PCI_E3 Gen PCIe 4.0, from Chipset) RAID Support: RAID 0, RAID 1, RAID 5, RAID 10 for SATA storage devices USB Ports: Rear: 4 x USB 2.0 1 x USB 5Gbps Type-A 1 x USB 10Gbps Type-C Front: 4 x USB 2.0 2 x USB 5Gbps Type-A Internal I/O Connectors: 1 x ATX Power Connector 1 x CPU Power Connector 1 x CPU Fan 2 x System Fan 2 x Front Panel (JFP) 1 x Chassis Intrusion (JCI) 1 x Front Audio (JAUD) 1 x Printer Port (JLPT) 1 x Com Port (JCOM) 1 x RGB LED Connector (JRGB) 1 x TPM Pin Header (Support TPM 2.0) 4 x USB 2.0 Ports 2 x USB 5Gbps Type-A Ports LED Feature: 4 x EZ Debug LED Back Panel Ports: VGA DisplayPort HDMI™ Keyboard / Mouse USB 2.0 LAN port Audio Connectors USB 3.2 Gen 1 5Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) Operating System: Supports Windows® 11 64-bit, Windows® 10 64-bit Form Factor: mATX (243.84mm x 243.84mm)

Read more less

Motherboard Specification Processor Support: Intel® Core™ 14th/13th/12th Gen, Intel® Pentium® Gold, and Celeron® Processors Chipset: Intel® B760 Chipset Memory Support: 2 DIMMs, Dual Channel DDR4-4800+MHz (OC) Graphics Ports: HDMI™ 1.4 (4K@30Hz), VGA (Requires Processor Graphics) Expansion Slots: 1 × PCIe 4.0 x16, 1 × PCIe 3.0 x1 Storage: 1 × M.2 Gen4 x4 64Gbps, 4 × SATA 6Gbps Ethernet: Realtek® RTL8111H Gigabit LAN USB: 4 × USB 3.2 Gen 1 (Type-A), 8 × USB 2.0 Audio: 8-Channel (7.1) HD Audio with Audio Boost

Read more less

Motherboard Specification Processor Support: Intel® LGA1700 (Core™ 14th, 13th, 12th Gen, Pentium® Gold, Celeron®) Chipset: Intel® H610 Memory Support: 2 x DIMM slots, max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Graphics Ports: 1 x HDMI™ port (4K@60Hz) Expansion Slots: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1 Storage: 1 x M.2 slot (PCIe 3.0 x4), 4 x SATA 6Gb/s Ethernet: 1 x Realtek 1Gb Ethernet Wireless & Bluetooth: Not included USB: 2 x USB 5Gbps, 4 x USB 2.0 rear; 1 x USB 5Gbps, 1 x USB 2.0 front Audio: Realtek 7.1 Surround Sound Audio CODEC Internal I/O Connectors: 1 x 4-pin CPU Fan header, 1 x 4-pin Chassis Fan header, 1 x M.2 slot Back Panel I/O Ports: 2 x USB 5Gbps, 4 x USB 2.0, 1 x HDMI™, 1 x Ethernet, 3 x Audio jacks, 1 x PS/2 port Form Factor: micro-ATX (9.2 inch x 8.0 inch)

Read more less

Motherboard Specification: Processor Support: Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors Chipset: H510 Memory Support: DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory Graphics Ports: 1 x HDMI 2.0, 1 x DisplayPort, 1 x D-Sub port Expansion Slots: Intel® 11th & 10th Gen Processors: 1 x PCIe 4.0/3.0 x16 slot Intel® H510 Chipset: 2 x PCIe 3.0 x1 slots Storage: 1 x M.2 slot (Key M) supports PCIe 3.0 x4 & SATA modes 4 x SATA 6Gb/s ports Ethernet: 1 x Intel® 1Gb Ethernet USB: Rear: 2 x USB 3.2 Gen 1 ports, 4 x USB 2.0 ports; Front: 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers Audio: Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC Internal I/O Connectors: Includes fan, power, storage, USB, and other headers Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Ethernet, audio, PS/2 Keyboard, PS/2 Mouse ports Form Factor: microATX (22.6cm x 21.1cm)

Read more less

CPU Specifications: Cores: 20 total (8 Performance-cores, 12 Efficient-cores) Threads: 20 Base Frequencies: Performance-cores: 3.9 GHz Efficient-cores: 3.3 GHz Max Turbo Frequencies: Total: 5.5 GHz Performance-cores: 5.4 GHz Efficient-cores: 4.6 GHz Cache: 30 MB Intel® Smart Cache 36 MB L2 Cache Processor Power: Base Power: 125W Max Turbo Power: 250W Intel® Deep Learning Boost: Supported Lithography: TSMC N3B AI Frameworks Supported: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN Launch Date: Q4'24 Max Memory: 192 GB (up to DDR5 6400 MT/s, ECC supported) GPU: Intel® Graphics, Base Frequency 300 MHz, Max Dynamic Frequency 2 GHz, 4 Xe-cores NPU: Intel® AI Boost with 13 TOPS (Int8) PCIe: Up to PCIe 5.0 (Max 24 lanes) Advanced Features: Intel® Thread Director: Yes Intel® Turbo Boost: Max Technology 3.0 Intel® vPro®: Eligibility for Intel vPro® Enterprise
