AMD's fastest 6 core processor for mainstream desktop, with 12 processing threads
Can deliver elite 100+ FPS performance in the world's most popular games
Bundled with the quiet, capable AMD Wraith Stealth cooler. System Memory Type: DDR4
4.6 GHz Max Boost, unlocked for overclocking, 32 MB of cache, DDR-3200 support
For the advanced Socket AM4 platform, can support PCIe 4.0 on X570 and B550 motherboards
Processor Specification
Total Cores: 6
Total Threads: 12
Max Turbo Frequency: Up to 4.6GHz
Base Frequency: 3.7GHz
Cache:
L2 Cache: 3MB
L3 Cache: 32MB
Processor Turbo Power: 65W - 150W
Max Memory Size: Up to 3200MT/s
Processor Graphics: N/A
Sockets Supported: AM4
Max Temperature: 95°C
Product number
L2749A
Scanner type
Flatbed; ADF
Scan Resolution
Scan Resolution, Optical
Up to 600 x 600 dpi (color and mono, ADF); Up to 1200 x 1200 dpi (color and mono, flatbed)
Scan Resolution, Hardware
Up to 600 x 600 dpi (color and mono, ADF); Up to 1200 x 1200 dpi (color and mono, flatbed)
Output Resolution Dpi Settings
75; 150; 200; 240; 300; 400; 500; 600; and 1200 ppi
Scan Speed
Scan speed in preview mode
Up to 8.33 sec, single image scan. (Low resolution preview scan of the whole scanner bed [Flatbed, Entire Scan Area, Color, 75 dpi])
Automatic document feeder scan speed
Up to 30 ppm/60 ipm
Scan speed OCR (A4)
OCR A4 (8.5 x 11 in) text page (ADF, 300 dpi, B&W, RTF): 6.37 sec for single image scan. 1.84 sec for single image save; OCR A4 (8.5 x 11 in) text page (Flatbed, 300 dpi, B&W, RTF): 7.8 sec for single image scan. 1.62 sec for single image save.
Task speed
OCR A4 (8.5 x 11 in) text page (ADF, 300 dpi, Color, RTF): 6.51 sec for single image scan. 4.45 sec for single image save; A4 (8.5 x 11 in) to e-mail (ADF, 300 dpi, Color, PDF): 6.43 sec for single image scan. 1.56 sec for single image send; OCR A4 (8.5 x 11 in) text page (Flatbed, 300 dpi, Color, RTF): 7.89 sec for single image scan. 4.43 sec for single image save; A4 (8.5 x 11 in) to e-mail (Flatbed, 300 dpi, Color, PDF): 7.89 sec for single image scan. 1.39 sec for single image send. [4 x 6-in is not supported. Slides to file and negative to file are not supported]
Scan speed footnote number
[1] Actual speeds may vary depending on scan resolution, connectivity type, computer performance and application software.
Scanner Specifications
Duty cycle (daily)
Recommended daily duty cycle: 4000 pages (ADF), 100 pages (Flatbed)
Bit Depth
24-bits external 48-bits internal
Auto document feeder capacity
Standard, 50 sheets (75 g/m² paper)
Scan size, maximum
216 x 356 mm
Scan size (ADF), maximum
216 x 3100 mm
Scan size ADF (minimum)
105 x 148 mm
Scan size, minimum
25.4 x 25.4 mm
Scan input modes
Scan front-panel function for Save as PDF, Save as JPEG, E-mail as PDF, E-mail as JPEG, Send to Cloud, Everyday Scan and Save as Editable Text (OCR). HP Scan in Win OS, HP Easy Scan/ICA in Mac OS and thrid parties applications via TWAIN.
Scan file format
For text & images: PDF, JPEG, PNG, BMP, TIFF, Text (.txt), Rich Text (rtf) and Searchable PDF.
Scanning options (ADF)
Single pass E-Duplex
Duplex ADF scanning
Yes
Scan technology
CMOS CIS (Contact Image Sensor)
Levels of grayscale
256
Color scanning
Yes
Multifeed detection
Yes
Light source (scanning)
Light Emitting Diode (LED)
Scanner advanced features
Blank page removal; Auto orientation; Auto color detect; Auto crop; Auto exposure; Hole removal; Straighten content; Erase edges; Clean up background; Auto threashold; Color drop out; OCR
Processor speed
550 MHz
Memory
1 GB
Connectivity and Communications
Network ready
Build-in Ethernet, Wi-Fi 802.11 b/g/n
?
Ports
USB 2.0 or USB 3.0 (SuperSpeed); Built-in Fast Ethernet 10/100/1000Base-TX network port
?
Connectivity, standard
USB 2.0 and USB 3.0 (SuperSpeed); Built-in Fast Ethernet 10/100/1000Base-TX network port
Twain version
TWAIN Certified. Version 2.1
Control panel
2.8-in (7.11-cm) Touchscreen, Buttons (Back, Home, Help)
Power
Power
Input Voltage: 100 to 240 VAC
Power supply type
External power adapter
Power Consumption Description
6.11 watts (Ready), 1.35 watts (Sleep), 0.05 watts (Auto-Off), 0.05 watts (Off)
Supported Printing Media
Media weights, supported, ADF
45 to 120 g/m²
Media size (ADF)
Letter; Legal; Executive; A4; A5; A6; B5; B5 (JIS)
Media types
Paper (banner, inkjet, photo, plain), envelopes, labels, cards (greeting, index)
Environmental
Operating temperature range
10 to 35°C
Storage temperature range
-40 to 60°C
Operating humidity range
15 to 80% RH (non-condensing)
Non-Operating Humidity Range
0 to 90% RH (non-condensing)
Acoustic power emissions
6.3 B(A)
Replaceable parts
Pick-up rollers; pick-up pads
System Requirements
Compatible Operating Systems
Win 7 or higher; Mac: OS X El Capitan 10.11
Minimum System Requirements
Windows 7 or higher; 2 GHz processor, 2 GB RAM, 170 MB hard disk space (driver-only install); USB 2.0, 1024 x 768 SVGA monitor
Mac compatible
Yes
Minimum System Requirements for Macintosh
Mac OS X El Capitan 10.11; 1 GB available hard disk space, USB or Ethernet port
Dimensions and Weight
Dimensions without stand (W x D x H)
520 x 387 x 145 mm
Maximum dimensions (W x D x H)
520 x 387 x 145 mm
?
Weight
5.98 kg
Box contents
What's in the box
HP ScanJet Pro 4500 fn1 Network Scanner; Install guide; HP Scan Software & Driver CD; HP Bonus Pack Software CD; Supporting flyers; Cushions; USB cable; Power adaptor; Power cords
Cable included
Yes, 1 USB
Software included
HP Scanner Device Driver, HP WIA scan driver, HP TWAIN scan driver, HP Scan, HP Scanner Tools Utility, HP Windows Installer, I.R.I.S. Readiris Pro, I.R.I.S. Cardiris, Nuance PaperPort, ISIS driver, Kofax VRS Pro
Warranty
Warranty
1 Year Limited Warranty (Return to HP/Dealer - Unit Exchange)
Certification and Compliance
Safety Approvals and Requirements
IEC 60950-1:2005 +A1 and all applicable amendments; CSA/UL 60950-1, 2nd edition (2007); EN 60950-1:2006 +A11 +A1 +A12+A2; EAC safety; Canada cUL CoC; China CCC; European Union CE; Kenya PVOC; Kuwait TER; Nigeria SON; Saudi Arabia SASO; South Africa NRCS; Taiwan BSMI; Ukraine safety approval
Electromagnetic Emission Standard
Class B Emissions; CISPR 22:2008 (International); European Union EMC Directive 2004/108/EC, EN 55022:2010 (CE mark); China GB9254-2008 (CCC); Taiwan CNS13438:2006 (BSMI); USA CFR47 Part 15, Subpart B (FCC); ICES-003:2012 Issue 5 (Canada); Australia C-tick (includes New Zealand); KN 22 and Korea KCC; EAC EMC Certificate; Ukraine EMC approval; EN 61000-3-2:2014 (harmonics); EN 61000-3-3:2013 (flicker); Immunity CISPR 24:2010, EN 50024:2010
ENERGY STAR® certified
Yes
NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency
4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
3rd Generation RT Cores: Up to 2X ray tracing performance
OC edition: 2655 MHz (OC mode)/ 2625 MHz (Default mode)
Axial-tech fans scaled up for 21% more airflow
Dual ball fan bearings last up to twice as long as conventional designs
Military-grade capacitors rated for 20K hours at 105C make the GPU power rail more durable
Vented exoskeleton adds structural rigidity and vents to increase heat reliability
Auto-Extreme precision automated manufacturing for higher reliability
GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring
