Motherboard Specification
Processor Support: AMD Socket AM5 for Ryzen™ 9000, 8000, & 7000 Series Desktop Processors.
Chipset: AMD X870 Chipset.
Memory Support: 4 x DIMM slots, max 192GB DDR5, supports up to 8000+MT/s (OC).
Graphics Ports: 1 x HDMI™ (4K@60Hz), 2 x USB4® (40Gbps, 4K@60Hz).
Expansion Slots: 1 x PCIe 5.0 x16 (Ryzen™ 9000 & 7000), 2 x PCIe 4.0 x16 (AMD X870).
Storage: 4 x M.2 slots, 2 x SATA 6Gb/s ports, PCIe 5.0/4.0/3.0 support.
Ethernet: 1 x Realtek 2.5Gb Ethernet, ASUS LANGuard.
Wireless & Bluetooth: No wireless/Bluetooth details in specs.
USB: 10 rear USB ports, 7 front USB ports (USB4®, Type-C®).
Audio: Realtek 7.1 Surround Sound, up to 24-Bit/192 kHz, premium audio capacitors.
Internal I/O Connectors: 24-pin power, 8-pin CPU power, 4 x 4-pin fan headers, USB connectors.
Back Panel I/O Ports: 2 x USB4®, 1 x USB 10Gbps, HDMI™, 2.5Gb Ethernet, 3 x Audio jacks.
Form Factor: ATX, 12 x 9.6 inches (30.5 cm x 24.4 cm).
Motherboard Specification
Motherboard Specifications - TUF GAMING B650-PLUS
Processor Support: AMD Socket AM5 for Ryzen™ 9000, 8000, and 7000 Series
Chipset: AMD B650
Memory Support: 4 x DIMM, Max. 128GB, DDR5 (Up to 7600+ OC), Dual Channel, Supports AMD EXPO™
Graphics Ports: 1 x DisplayPort (8K@60Hz), 1 x HDMI® (4K@60Hz)
Expansion Slots:
1 x PCIe 4.0/3.0 x16
1 x PCIe 4.0 x16 (supports x8/x4 mode, varies by CPU)
1 x PCIe 4.0/3.0 x16 (supports x4 mode)
2 x PCIe 4.0/3.0 x1
Storage:
3 x M.2 slots (PCIe 5.0/4.0)
4 x SATA 6Gb/s ports
Supports RAID 0/1/10
Ethernet: Realtek 2.5Gb Ethernet, TUF LANGuard
Wireless & Bluetooth: Not specified
USB:
Rear: 1 x USB 3.2 Gen 2x2 Type-C, 3 x USB 3.2 Gen 2 (2 x Type-A, 1 x Type-C), 4 x USB 2.0
Front: 1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports)
Audio: Realtek 7.1 Surround Sound, Jack-detection, Multi-streaming, Premium capacitors
Internal I/O Connectors:
3 x M.2 slots, 4 x SATA 6Gb/s
1 x 24-pin ATX power, 1 x 8-pin +12V, 1 x 4-pin +12V
1 x CPU fan header, 1 x CPU OPT fan, 1 x AIO pump, 4 x chassis fan headers
3 x Addressable Gen 2 headers, 1 x Aura RGB header
1 x Thunderbolt™ (USB4®) header
Back Panel I/O Ports:
1 x USB 3.2 Gen 2x2 Type-C, 3 x USB 3.2 Gen 2 (2 x Type-A, 1 x Type-C), 4 x USB 2.0
1 x DisplayPort, 1 x HDMI
1 x Realtek 2.5Gb Ethernet, 5 x Audio jacks
1 x BIOS FlashBack™ button
Form Factor: ATX (30.5 cm x 24.4 cm)
Motherboard Specification
Processor Support: AMD Socket AM5 for AMD Ryzen™ 9000, 8000 & 7000 Series Desktop Processors
Chipset: AMD X870
Memory Support: 4 x DIMM slots, max. 256GB DDR5, up to 8000+MT/s(OC), ECC & Non-ECC, Dual Channel, Supports EXPO™ & AEMP
Graphics Ports: 1 x DisplayPort (8K@30Hz), 1 x HDMI™ (4K@60Hz), 2 x USB4® (40Gbps) with Display Output
Expansion Slots:
Ryzen™ 9000 & 7000: 1 x PCIe 5.0 x16 (x16 mode)
Ryzen™ 8000: 1 x PCIe 4.0 x16 (x8/x4 mode)
AMD X870 Chipset: 1 x PCIe 4.0 x16 (x4 mode)
Storage:
4 x M.2 slots (PCIe 5.0 & PCIe 4.0 support, varies by CPU)
2 x SATA 6Gb/s ports
Supports RAID 0/1/5/10 (PCIe RAID 5 only with Ryzen 9000)
Ethernet: 1 x Intel® 2.5Gb Ethernet, ASUS LANGuard
Wireless & Bluetooth: Wi-Fi 7 (2x2, up to 2.9Gbps), Bluetooth® v5.4
USB:
Rear (12 ports): 2 x USB4® (40Gbps Type-C), 6 x USB 10Gbps (5 x Type-A, 1 x Type-C with 30W PD), 4 x USB 5Gbps (Type-A)
Front (9 ports): 1 x USB 20Gbps (Type-C), 4 x USB 5Gbps, 4 x USB 2.0
Audio: ROG SupremeFX 7.1 HD Audio CODEC (ALC4080), 120dB SNR stereo, 110dB SNR recording, Savitech SV3H712 AMP, Optical S/PDIF
Internal I/O Connectors:
1 x 24-pin Main Power, 2 x 8-pin CPU Power
4 x M.2 slots, 2 x SATA 6Gb/s ports
1 x USB 20Gbps (Type-C), 4 x USB 5Gbps, 4 x USB 2.0
6 x Fan headers, 1 x AIO Pump header
3 x Addressable Gen 2 RGB headers
Back Panel I/O Ports:
2 x USB4® (40Gbps Type-C), 6 x USB 10Gbps, 4 x USB 5Gbps
1 x DisplayPort, 1 x HDMI™
1 x Intel® 2.5Gb Ethernet, 1 x Wi-Fi module
2 x Audio jacks, 1 x Optical S/PDIF
1 x BIOS FlashBack™, 1 x Clear CMOS button
Form Factor: ATX (30.5 cm x 24.4 cm)
Motherboard Specification
Processor Support: AMD Socket AM5 for AMD Ryzen™ 9000, 8000 & 7000 Series Desktop Processors
Chipset: AMD X870 Chipset
Memory Support: 4 x DIMM slots, max. 192GB, DDR5, supports up to 8000+MT/s (OC), ECC and Non-ECC
Graphics Ports: 1 x HDMI™, 2 x USB4® (40Gbps) ports (supports USB Type-C® display outputs)
Expansion Slots:
1 x PCIe 5.0 x16 (for Ryzen™ 9000 & 7000 Series)
1 x PCIe 4.0 x16 (for Ryzen™ 8000 Series)
3 x PCIe 4.0 x16 (supports x1 mode)
Storage:
4 x M.2 slots (supports PCIe 5.0, 4.0, 3.0)
2 x SATA 6Gb/s ports
Ethernet: 1 x Realtek 2.5Gb Ethernet, ASUS LANGuard
Wireless & Bluetooth: Wi-Fi 7 (2x2) up to 2.9Gbps, Bluetooth 5.4
USB:
Rear: 2 x USB4® (40Gbps), 1 x USB 10Gbps, 3 x USB 5Gbps, 4 x USB 2.0
Front: 1 x USB 10Gbps, 1 x USB 5Gbps header, 2 x USB 2.0 headers
Audio: Realtek 7.1 Surround Sound HD Audio CODEC, supports up to 24-Bit/192kHz playback
Internal I/O Connectors:
4 x 4-pin fan headers, 2 x 8-pin CPU power connectors
USB headers, M.2 slots, SATA connectors
Back Panel I/O Ports:
2 x USB4® (40Gbps), 1 x USB 10Gbps, 3 x USB 5Gbps, 4 x USB 2.0, HDMI™, Ethernet port, Audio jacks, BIOS FlashBack™ button
Form Factor: ATX (12 x 9.6 inches / 30.5 x 24.4 cm)
Comprehensive cooling: VRM heatsink, PCH heatsink, and Fan Xpert 2+
Ultrafast connectivity: M.2 support, 1 Gb Ethernet, and USB 3.2 Gen 2 Type-A
5X Protection III: Multiple hardware safeguards for all-around system protection
Aura Sync RGB Lighting: Onboard connector for RGB LED strips, easily synced with an ever-growing portfolio of Aura Sync-capable hardware
TUF GAMING Z790-BTF WIFI Motherboard Specifications
Processor Support:Intel® Core™ 14th, 13th, 12th Gen, Pentium® Gold, Celeron® (LGA1700)Chipset:Intel® Z790Memory Support:4 x DDR5 slots, up to 192GB, 7200(OC) MHzGraphics Ports:1 x DisplayPort 1.4 (4K@60Hz), 1 x HDMI™ 2.1 (4K@60Hz)Expansion Slots:1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16 (x4 mode), 1 x PCIe 4.0 x4Storage:4 x M.2 slots, 4 x SATA 6Gb/s portsEthernet:Intel® 2.5GbWireless & Bluetooth:Wi-Fi 7 (802.11be), Bluetooth® v5.4USB:Rear: 1 x USB 20Gbps (Type-C®), 3 x USB 10Gbps, 4 x USB 5GbpsFront: 1 x USB 10Gbps (Type-C®), 1 x USB 5Gbps header, 2 x USB 2.0 headersAudio:Realtek ALC1220P 7.1 Surround, S/PDIF outInternal I/O Connectors:Fan headers, Power connectors, M.2, SATA, USB headers, RGB headersBack Panel I/O Ports:USB, DisplayPort, HDMI™, Ethernet, Audio jacksForm Factor:ATX (30.5 cm x 24.4 cm)
CPU Support: Intel® Core™ Ultra Processors (LGA 1851), supports Intel® Turbo Boost 2.0/3.0.
Chipset: Intel® Z890.
Memory: 4 x DIMM slots, up to 256GB DDR5, supports up to 8666+ MT/s (OC).
Graphics: 1 x DisplayPort, 1 x HDMI 2.1 (4K@60Hz), 1 x Thunderbolt™ 4 USB Type-C® (8K@60Hz).
Expansion: 1 x PCIe 5.0 x16, 3 x PCIe 4.0 x16 slots.
Storage: 4 x M.2 slots, 4 x SATA 6Gb/s ports, supports RAID.
Ethernet: Realtek 2.5Gb Ethernet.
Wireless: Wi-Fi 7 (2x2) up to 2.9Gbps, Bluetooth 5.4.
USB Ports: 1 x Thunderbolt™ 4 USB Type-C®, 1 x USB 10Gbps, 6 x USB 5Gbps, 4 x USB 2.0.
Audio: Realtek 7.1 Surround Sound, HD Audio CODEC.
Form Factor: ATX (12" x 9.6").
Motherboard Specification:
Processor Support: Intel® Socket LGA1700 for 13th & 14th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
Chipset: Intel® B760 Chipset
Memory Support: 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
Graphics Ports: 1 x DisplayPort, 1 x HDMITM port
Expansion Slots:
Intel® 13th & 12th Gen Processors: 1 x PCIe 5.0 x16 slot
Intel® B760 Chipset: 1 x PCIe 3.0 x16 slot, 2 x PCIe 3.0 x1 slots
Storage:
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
Intel® 13th & 12th Gen Processors: M.2_1 slot (Key M) supports PCIe 4.0 x4 mode
Intel® B760 Chipset: M.2_2 slot (Key M) supports PCIe 4.0 x4 mode, M.2_3 slot (Key M) supports PCIe 4.0 x4 mode, 4 x SATA 6Gb/s ports
Ethernet: 1 x Realtek 2.5Gb Ethernet
Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2
USB: Rear: 1 x USB 3.2 Gen 2x2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 1 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers
Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
Internal I/O Connectors: Includes fan, power, storage, USB, and other headers
Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Wi-Fi Module, Ethernet, audio, and S/PDIF out ports
Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
Motherboard Specification:
Processor Support: Intel® Socket LGA1700 for 13th & 14th Gen Intel® Core™ & 12th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
Chipset: Intel® B760 Chipset
Memory Support: 4 x DIMM, Max. 192GB, DDR5 7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
Graphics Ports: 1 x DisplayPort, 1 x HDMITM port
Expansion Slots:
Intel® 13th & 12th Gen Processors: 1 x PCIe 5.0 x16 slot
Intel® B760 Chipset: 1 x PCIe 3.0 x16 slot, 2 x PCIe 3.0 x1 slots
Storage:
Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
Intel® 13th & 12th Gen Processors: M.2_1 slot (Key M) supports PCIe 4.0 x4 mode
Intel® B760 Chipset: M.2_2 slot (Key M) supports PCIe 4.0 x4 mode, M.2_3 slot (Key M) supports PCIe 4.0 x4 mode, 4 x SATA 6Gb/s ports
Ethernet: 1 x Realtek 2.5Gb Ethernet
Wireless & Bluetooth: Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Bluetooth® v5.2
USB: Rear: 1 x USB 3.2 Gen 2x2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1 Type-A, 1 x USB 2.0 Type-A; Front: 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers
Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC
Internal I/O Connectors: Includes fan, power, storage, USB, and other headers
Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Wi-Fi Module, Ethernet, audio, and S/PDIF out ports
Form Factor: ATX Form Factor, 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
Related items
Ultrafast Connectivity: PCIe 5.0, three PCIe 4.0 M.2, Realtek 2.5Gb Ethernet, USB 3.2 Gen 2x2 Type-C®, front USB 3.2 Gen 1 Type-C® and Thunderbolt™ (USB4®) header support
Comprehensive Cooling: VRM heatsinks, M.2 heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 2+
Exclusive Memory Technology: ASUS Enhanced Memory Profile II and ASUS OptiMem II
Aura Sync RGB Lighting: Onboard Addressable Gen 2 headers and Aura RGB header for RGB LED strips, easily synced with Aura Sync-capable hardware
Motherboard Specification
Processor Support: Intel® LGA1700 (Core™ 14th, 13th, 12th Gen, Pentium® Gold, Celeron®)
Chipset: Intel® H610
Memory Support: 2 x DIMM slots, max. 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133
Graphics Ports: 1 x HDMI™ port (4K@60Hz)
Expansion Slots: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
Storage: 1 x M.2 slot (PCIe 3.0 x4), 4 x SATA 6Gb/s
Ethernet: 1 x Realtek 1Gb Ethernet
Wireless & Bluetooth: Not included
USB: 2 x USB 5Gbps, 4 x USB 2.0 rear; 1 x USB 5Gbps, 1 x USB 2.0 front
Audio: Realtek 7.1 Surround Sound Audio CODEC
Internal I/O Connectors: 1 x 4-pin CPU Fan header, 1 x 4-pin Chassis Fan header, 1 x M.2 slot
Back Panel I/O Ports: 2 x USB 5Gbps, 4 x USB 2.0, 1 x HDMI™, 1 x Ethernet, 3 x Audio jacks, 1 x PS/2 port
Form Factor: micro-ATX (9.2 inch x 8.0 inch)
Motherboard Specification:
Processor Support: Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
Chipset: H510
Memory Support: DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Graphics Ports: 1 x HDMI 2.0, 1 x DisplayPort, 1 x D-Sub port
Expansion Slots:
Intel® 11th & 10th Gen Processors: 1 x PCIe 4.0/3.0 x16 slot
Intel® H510 Chipset: 2 x PCIe 3.0 x1 slots
Storage:
1 x M.2 slot (Key M) supports PCIe 3.0 x4 & SATA modes
4 x SATA 6Gb/s ports
Ethernet: 1 x Intel® 1Gb Ethernet
USB: Rear: 2 x USB 3.2 Gen 1 ports, 4 x USB 2.0 ports; Front: 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers
Audio: Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC
Internal I/O Connectors: Includes fan, power, storage, USB, and other headers
Back Panel I/O Ports: Includes USB, DisplayPort, HDMI™, Ethernet, audio, PS/2 Keyboard, PS/2 Mouse ports
Form Factor: microATX (22.6cm x 21.1cm)
