Model Number
MasterBox MB320L ARGB: MCB-B320L-KGNN-S01, MasterBox MB320L ARGB with Hub: MCB-B320L-KGNN-S02
Color(s)
Black
Materials
Steel, Plastic, Tempered Glass
Dimensions (L x W x H)
435.5 x 217.5 x 410mm
Weight
5.47kg
Motherboard Support
Micro ATX, Mini ITX
Expansion Slots
4
5.25" Drive Bays
N/A
3.5" Drive Bays
2
2.5" Drive Bays
2
I/O Panel
2x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack
ARGB Controller
MasterBox MB320L ARGB: 1x ARGB 1-to-3 Splitter, MasterBox MB320L ARGB with Hub: 1x ARGB Hub
Pre-installed Fans - Front
2x 120mm CF120 ARGB Fan
Fan Support - Top
2x 120/140mm
Fan Support - Front
3 x 120mm* / 2 x 140mm, *can only mount behind the front plate
Fan Support - Rear
1x 120mm
Radiator Support - Top
120mm, 240mm
Radiator Support - Front
120mm, 140mm, 240mm, 280mm
Radiator Support - Rear
120mm
Clearance - CPU Cooler
166mm/6.54"
Clearance - PSU
325mm (w/o front radiator & HDD cage), 140mm (HDD cage in backmost position)
Clearance - GFX
344mm
Cable Routing
18-22mm
Dust Filters
Front, Top, Bottom
Power Supply Support
Bottom Mount, ATX
Warranty
2 years
Series
MasterBox Series
Size
Mini Tower
