| Model Number |
MasterBox MB320L ARGB: MCB-B320L-KGNN-S01, MasterBox MB320L ARGB with Hub: MCB-B320L-KGNN-S02 |
|
|
|
| Materials |
Steel, Plastic, Tempered Glass |
|
| Dimensions (L x W x H) |
435.5 x 217.5 x 410mm |
|
|
|
| Motherboard Support |
Micro ATX, Mini ITX |
|
|
|
|
|
|
|
|
|
| I/O Panel |
2x USB 3.2 Gen 1 (USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack |
|
| ARGB Controller |
MasterBox MB320L ARGB: 1x ARGB 1-to-3 Splitter, MasterBox MB320L ARGB with Hub: 1x ARGB Hub |
|
| Pre-installed Fans - Front |
2x 120mm CF120 ARGB Fan |
|
| Fan Support - Top |
2x 120/140mm |
|
| Fan Support - Front |
3 x 120mm* / 2 x 140mm, *can only mount behind the front plate |
|
| Fan Support - Rear |
1x 120mm |
|
| Radiator Support - Top |
120mm, 240mm |
|
| Radiator Support - Front |
120mm, 140mm, 240mm, 280mm |
|
| Radiator Support - Rear |
120mm |
|
| Clearance - CPU Cooler |
166mm/6.54" |
|
| Clearance - PSU |
325mm (w/o front radiator & HDD cage), 140mm (HDD cage in backmost position) |
|
|
|
|
|
| Dust Filters |
Front, Top, Bottom |
|
| Power Supply Support |
Bottom Mount, ATX |
|
|
|
|
|
|
|
