Core Specifications
GPU: NVIDIA GeForce RTX 5070
CUDA Cores: 6144
Video Memory: 12GB GDDR7
Memory Interface: 192-bit
Engine Clock: 2542 MHz
Memory Speed: 28 Gbps
Interface: PCI Express 5.0 x16
Display & Graphics
Display Outputs:
3 x DisplayPort 2.1b with UHBR20
Supports up to 4K @ 480Hz or 8K @ 165Hz (DSC)
1 x HDMI 2.1b
Supports 4K @ 120Hz HDR, 8K @ 60Hz HDR, Variable Refresh Rate
HDCP Support: Version 2.3
Multi-Display Support: Up to 4 displays simultaneously
Power & Cooling
Recommended PSU: 650W
Power Consumption: 250W
Power Input: 1 x 12V-2x6 connector
Cooling Solution: IceStorm 2.0
Slot Size: Dual-slot
API & OS Support
DirectX: Microsoft DirectX® 12 Ultimate
OpenGL: Version 4.6
Operating System:
Windows 11 64-bit
Windows 10 64-bit (version 1809 or later)
Physical Dimensions
Card Size:
Length: 304.4 mm
Width: 115.8 mm
Height: 41.6 mm
(12" x 4.6" x 1.6")
Accessories Included
User Manual
2 x 8-pin to 16-pin power adapter cables
GPU Support Stand
available In Iraq
Graphics Processor: NVIDIA GeForce RTX 5060 TiCUDA Cores: 4608Video Memory: 16GB GDDR7Memory Interface: 128-bitCore Clock Speed: 2602 MHzMemory Speed: 28 GbpsBus Interface: PCI Express 5.0 x8
Display & Connectivity
3 x DisplayPort 2.1b (UHBR20)Supports up to 4K @ 480Hz or 8K @ 165Hz with DSC
1 x HDMI 2.1bSupports 4K @ 480Hz HDR or 8K @ 120Hz HDR with DSC, and Variable Refresh Rate (VRR)
Multi-Display Support: Up to 4 monitors
HDCP Support: Version 2.3
Performance & Power
Recommended PSU: 600W
Power Consumption: 180W
Power Connector: 1 x 8-pin
Cooling & Build
Cooling System: IceStorm 2.0
Slot Size: Dual-slot
Card Dimensions: 220.5mm (L) x 120.25mm (W) x 41.6mm (H)
SLI Support: Not supported
Software & Compatibility
Operating System: Windows 11 / 10 (64-bit, version 1809 or newer)
API Support: DirectX 12 Ultimate, OpenGL 4.6
Included in the Box:✔ Graphics Card✔ User Manual
available In Iraq
Core Specifications
GPU: NVIDIA GeForce RTX 5080
CUDA Cores: 10,752
Video Memory: 16GB GDDR7
Memory Interface: 256-bit
Engine Clock: 2640 MHz
Memory Speed: 30 Gbps
Bus Interface: PCI Express 5.0 x16
Display Outputs
3 x DisplayPort 2.1b (UHBR20)
Up to 4K @ 480Hz or 8K @ 165Hz (DSC)
1 x HDMI 2.1b Connector
Supports 4K @ 480Hz HDR or 8K @ 120Hz HDR (DSC)
Supports VRR (Variable Refresh Rate)
HDCP Support: Version 2.3
Multi-Display Capability: Up to 4 displays
Power & Cooling
Recommended Power Supply: 850W
Power Consumption: 360W
High power draw – ensure PSU compliance before installation
Power Input: 1 x 12V-2x6 connector
Cooling System: IceStorm 3.0 Advanced Airflow
Slot Size: 3.5-slot
SLI Support: Not supported
OS & API Compatibility
DirectX: Microsoft DirectX® 12 Ultimate
OpenGL: Version 4.6
Operating Systems Supported:
Windows 11 64-bit
Windows 10 64-bit (version 1809 or later)
Physical Dimensions
Length: 329.7 mm
Width: 137.8 mm
Height: 67.8 mm
Dimensions (inches): 13" x 5.4" x 2.7"
Included Accessories
User Manual
3 x 8-pin to 16-pin Adapter Cables
SPECTRA LINK RGB Sync Cable
GPU Support Stand
available In Iraq
