Main Input Voltage | 120 V |
---|---|
Other Input Voltage | 110 V 125 V |
Main Output Voltage | 120 V |
Other Output Voltage | 110 V 125 V |
Rated power in W | 900 W |
Rated power in VA | 1440 VA |
Product or component type | Uninterruptible power supply (UPS) |
Input Connection Type | NEMA 5-15P |
output connection type | 6 NEMA 5-15R |
Number of rack unit | 2U |
Cable length | 2.44 m |
Number of cables | 1 |
Battery type | Lead-acid battery |
Provided equipment | Documentation CD Installation guide Rack mounting brackets USB cable |
Software package | SmartConnect software for remote power monitoring feature availability varies by terms of use |
---|
Run Time | View Runtime Graph |
---|---|
Efficiency | View Efficiency Graph |
Extended runtime | 0 |
Number of battery filled slots | 0 |
Number of battery free slots | 0 |
Battery recharge time | 3 h |
Number of battery replacement quantity | 1 |
Battery life | 4…6 year(s) |
Replacement battery | APCRBC157 |
Battery power in VAH | 260 VAh runtime |
Battery charger power | 86 W rated |
Number of power module filled slots | 0 |
---|---|
Number of power module free slots | 0 |
product web sub-family | Cloud-enabled monitoring |
Redundant | No |
Colour | Black |
---|---|
Height | 8.6 cm |
Width | 43.2 cm |
Depth | 47.7 cm |
Net weight | 25.3 kg |
Mounting location | Front |
Mounting preference | Lower |
Mounting mode | Rack-mounted |
Two post mountable | 0 |
USB compatible | Yes |
Input voltage limits | 85...136 V adjustable 93...130 V |
---|---|
Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
Harmonic distortion | Less than 5 % |
---|---|
Maximum configurable power in VA | 1440 VA |
Maximum configurable power in W | 900 W |
Transfer time | 6 ms typical : 10 ms maximum |
UPS type | Line interactive |
Wave type | Sine wave |
Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
Product certifications | cULus ENERGY STAR V2.0 (USA) |
---|---|
Equipment protection policy | Lifetime : $150000 |
Acoustic level | 45 dBA |
---|---|
Heat dissipation | 225 Btu/h |
Operating altitude | 0...10000 ft |
Ambient air temperature for operation | 0…40 °C |
Ambient air temperature for storage | -15…45 °C |
Storage altitude | 0.00…15240.00 m |
Relative humidity | 0…95 % |
Storage Relative Humidity | 0…95 % |
control panel | Multifunction LCD status and control console |
---|---|
Free slots | 0 |
Communication port support | SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
Alarm | Alarm when on battery : distinctive low battery alarm : configurable delays |
Surge energy rate | 680 J |
---|---|
Noise suppression | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Unit Type of Package 1 | PCE |
---|---|
Number of Units in Package 1 | 1 |
Package 1 Height | 23.5 cm |
Package 1 Width | 61 cm |
Package 1 Length | 59 cm |
Package 1 Weight | 29.01 kg |
