| CPU Support |
LGA1700 socket
Supports Intel® 14th, 13th, and 12th Gen Core™, Pentium® Gold, and Celeron® processors |
| Chipset |
Intel® B760 Express |
| Memory Support |
2 x DDR5 DIMM slots (up to 96 GB)
Supports up to DDR5-7200(O.C.)
Dual-channel, ECC (non-ECC mode), and XMP support |
| Graphics Support |
Integrated Intel® UHD Graphics
1 x D-Sub, 1 x DisplayPort, 1 x HDMI
Triple display support |
| Audio |
Realtek® Audio CODEC
Supports 2/4/5.1/7.1-channel HD Audio |
| LAN |
Realtek® Gigabit Ethernet (1 Gbps) |
| Expansion Slots |
1 x PCIe 4.0 x16 slot (CPU)
1 x PCIe 3.0 x1 slot (Chipset) |
| Storage Options |
1 x M.2 PCIe 4.0 x4/x2 (CPU)
1 x M.2 PCIe 4.0 x4/x2 (Chipset)
4 x SATA 6Gb/s |
| USB Ports |
6 x USB 3.2 Gen 1
6 x USB 2.0/1.1 |
| Back I/O Ports |
2 x USB 2.0
4 x USB 3.2 Gen 1
D-Sub, HDMI, DisplayPort
RJ-45 LAN port
3 x Audio jacks |
| Internal I/O |
ATX 24-pin & 8-pin power
Fan headers, USB headers, TPM, front panel, RGB LED, etc. |
| BIOS |
128 Mbit AMI UEFI BIOS
Q-Flash support |
| Form Factor |
Micro ATX (23.0 x 21.5 cm) |
| Software |
GIGABYTE Control Center (GCC)
Norton® Security OEM
LAN Bandwidth Manager |
| OS Support |
Windows 11 64-bit / Windows 10 64-bit |
