Key Features
Superb Productivity
Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700)
PCIe Gen5 for graphics
Dual Channel DDR5 memory support
Rock-Solid Durability
7+1+1 Power Phase Design
Dr.MOS for VCore + GT
Ultrafast Connectivity
2.5G LAN with Dragon RTL8125BG
USB 3.2 Gen1 Type-C (Front & Rear)
Triple Hyper M.2 (PCIe Gen4 x4)
EZ Tools
ASRock Auto Driver Installer
ASRock Post Status Checker
ASRock EZ Mode BIOS
CPU Support
LGA1700 socket
14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® CPUs
Supports Intel® Hybrid Technology, Turbo Boost Max 3.0, TVB, and ABT
Memory
4 x DDR5 DIMM slots, up to 256GB
Speeds: Up to DDR5-7200+ (OC)*
Dual Channel, Non-ECC, Un-buffered
Supports Intel® XMP 3.0
Native speed varies by configuration:
1DPC 1R: 7200+ MHz
1DPC 2R: 6000+ MHz
2DPC 1R: 5600+ MHz
2DPC 2R: 4800+ MHz
Graphics Support
Integrated Intel® Xe Graphics (Gen 12)
1 x HDMI 2.1 (4K@60Hz, HDCP 2.3)
1 x DisplayPort 1.4 (up to 8K@60Hz / 5K@120Hz)
Audio
Realtek ALC897 7.1 CH HD Audio CODEC
Networking
2.5 Gigabit LAN (Dragon RTL8125BG)
Smart bandwidth control with gaming/browser/streaming modes
Expansion Slots
1 x PCIe 5.0 x16 (Graphics, from CPU)
1 x PCIe 3.0 x16 (x4 mode, from chipset)
1 x M.2 (Key E) for Wi-Fi/BT module (Intel CNVi supported)
Supports AMD CrossFire™
Storage
3 x Hyper M.2 (PCIe Gen4x4, up to 64 Gb/s)
4 x SATA 6Gb/s ports
Intel® VMD supported
NVMe & SATA RAID 0/1/5/10 supported
USB Ports
Rear I/O:
1 x USB 3.2 Gen1 Type-C
3 x USB 3.2 Gen1 Type-A
2 x USB 2.0
1 x PS/2 keyboard/mouse combo
HDMI, DisplayPort
RJ-45 LAN
HD Audio jacks
Internal:
1 x USB 3.2 Gen1 Type-C header
1 x USB 3.2 Gen1 header (2 ports)
2 x USB 2.0 headers (4 ports)
Headers & Connectors
1 x 24-pin ATX power
1 x 8-pin 12V Hi-Density power
1 x CPU fan (4-pin)
1 x CPU water pump fan (4-pin, 2A)
4 x Chassis/water pump fan headers (4-pin, 2A)
1 x RGB LED header (12V)
3 x Addressable RGB headers (5V)
1 x Front panel audio
1 x TPM header
1 x Thunderbolt™ AIC connector
1 x Front panel Type-C USB 3.2 Gen1 header
1 x SPI TPM header
Chassis intrusion, speaker header
BIOS & Utilities
128Mb AMI UEFI BIOS
ASRock EZ Mode & Full HD UEFI
Auto Driver Installer, Instant Flash, Easy RAID Installer
ASRock A-Tuning & Polychrome RGB Software
ASRock Live Update & App Shop
Accessories Included
User Manual
I/O Shield
2 x SATA Cables
4 x M.2 Screws
1 x M.2 Standoff
Operating System Support
Windows 10 64-bit
Windows 11 64-bit
Form Factor: Micro ATX (24.4 cm x 24.4 cm)Certifications: FCC, CE, ErP/EuP Ready
available In Iraq
From the manufacturer
PRIME Z490-PPRIME Z490-PPRIME Z490-PPRIME Z490-P
Intel Z490 (LGA 1200) ATX motherboard with dual M.2, 11 DrMOS power stages, 1 Gb Ethernet, HDMI, DisplayPort, SATA 6Gbps, USB 3.2 Gen 2, Thunderbolt 3 support, and Aura Sync RGB Lighting
Intel LGA 1200 socket: Ready for 10th Gen Intel Core processors
Enhanced power solution: 10+1 DrMOS power stages, 6-layer PCB, ProCool connector, alloy chokes and durable capacitors for stable power delivery
Comprehensive cooling: VRM heatsink, PCH heatsink, hybrid fan headers and Fan Xpert 4
ASUS OptiMem II: Careful routing of traces and vias, plus ground layer optimizations to preserve signal integrity for improved memory overclocking
Ultrafast connectivity: Dual M.2, 1 Gb Ethernet, USB 3.2 Gen 2 Type-A and Thunderbolt 3 support
Features
VRM Heatsink and Thermal Pads
Two massive VRM heatsinks with underneath thermal pads improve heat transfer from the MOSFETs and chokes for better cooling performance
Cooler by Design
Prime Z490 series features comprehensive cooling controls that are configurable via Fan Xpert 4 software or via the UEFI BIOS.
Multiple Temperature Sources
AIO Pump Header
Smart Protection
4-Pin PWM/DC Fan
Robust Power Design
Stable power is essential to extract every last bit of performance out of 10th Generation Intel Core processors, Prime Z490 is geared to cater to the demands of these high-core count CPUs.
1. ProCool Connector
2. 10+1 DrMOS Power Stages
Dual M.2 (up to 32 Gbps)
Dual M.2 slots support data-transfer speeds of up to 32 Gbps via x4 PCI Express 3.0 bandwidth, enabling quicker boot-up and app load times with OS or application drives.
USB 3.2 Gen 2 Type-A
Numerous USB ports support high-end rigs loaded with peripherals, including a rear-panel USB Type-A connectors with fast USB 3.2 Gen 2 connectivity for compatible cases
Thunderbolt 3 Support
Prime Z490-P supports ThunderboltEX 3-TR, an Intel certified Thunderbolt 3 add-on card that enables bi-directional speeds of up to 40 Gbps via a single cable. Additionally, an integrated Thunderbolt 3 header can support up to six devices in a daisy-chain and provide up to 100 watts of power to fast-charge devices
